Yuqori quvvatli kon tarmog'i

KAZA TUNELI MUSTAHKAMLASH GEOGRIDI

MTTVS tomonidan ishlab chiqarilgan kon geogrid^®konchilik innovatsiyasini yangi bosqichga ko'tardi. Bu anʼanaviy poʻlat/metall toʻrning eng yaxshi oʻrnini bosuvchi va togʻ jinslari va qattiq jinslarni yumshoq yer ostidan qazib olish uchun mos boʻlgan yuqori mustahkamlikdagi yuqori-polimer biaksial geogrid seriyasidir. Ikkita xom ashyodan ishlab chiqarilgan geogridlar mavjud: poliester va polipropilen, ularning har biri o'ziga xos xususiyatlarga va foydalanishga ega. Ulardan biri shaxta tunnellarining tomi uchun ideal, ikkinchisi-shaxta qovurg‘alari/devorlari uchun tikilgan. MTTVS^®kon geogrid mukammal ishlash va xavfsizlik afzalliklariga ega va moslashtirilgan bo'lishi mumkin. Uning tuzilishining eng yaxshi ta'siriga erishish uchun ma'lum rulon uzunligi, kengligi va to'r diafragma / ochilish o'lchamiga ko'ra ishlab chiqarilishi mumkin.

TURLARI:

Shaxtaning geogrid tomi

● The elongation is low, the actual data is 4.1 percent .

● It weighs about 0.9-1.3 kg per square meter, which is only 1/3 of the weight of the metal protective net. The size can be freely cut to facilitate on-site management.

● Good flexibility, reduces labor intensity of workers, and can effectively improve work efficiency

● Advanced flame retardant properties and antistatic coating (FRAS).

● Corrosion resistant, chemically and biologically inert.

● The breaking force of a single mesh belt of 8 steel wires>4000N

● It can provide ultra-high tensile strength up to 1000X1000 kN/m.

● The length, width and nominal aperture size of 25mm-100mm can be customized without affecting the structural integrity

● Used on the roof of mine tunnels.

Shaxta geogrid Rib

● Friction is not easy to generate static electricity. In the coal mine environment, the average surface resistance of the plastic mesh is 1109Ω the following.

● Good flame retardant performance. In an open flame environment, it only melts but does not burn, even if it burns within 10 seconds from the fire, it will be extinguished.

● Easy to wash coal. The density of the plastic net is around 0.92. Less than the density of water, during the coal washing process, the broken mesh floats on the water surface and is easy to be washed away.

● It is convenient for construction and transportation.

● Corrosion resistance, anti-aging, chemically and biologically inert.

● Both vertical and horizontal directions have strong bearing capacity. The ribs and ribs formed by two-way stretching are perpendicular to each other. This structure enables the pressure applied to the mesh surface to be effectively transmitted to the surrounding ribs through the nodes, which improves the overall pressure-bearing capacity of the mesh surface. When an external force is applied to a certain rib (or rib), the external force is evenly distributed to other ribs (or ribs), which reduces the concentrated bearing capacity of a single root, so it is not easy to cause the ribs to break. The mesh creep is small and the mesh size is uniform, which can effectively prevent the falling of the broken coal and protect the safe operation of workers and mine carts.

● The length, width and nominal aperture size can be customized without affecting the structural integrity.

● It is used for the ribs of mine tunnels, and can also be used as a supporting material for various roadways such as bolting roadways, supporting roadways, and bolting and shotcreting roadways. When used for mine roof, it must be used together with two or more layers.

FOYDALARI:

● Safety

● Light weight

● Antistatic

● Flame retardant

● Environmental friendly

● Repeated use

● Easy to install

● Life extension

● Corrosion resistance

● Save costs

Yuqori quvvatli PP tog'-kon sanoati Grid Rid Spetsifikatsiyasi

Eslatma: MD Mashina yo'nalishini bildiradi; TD ko'ndalang yo'nalishni bildiradi.

Yuqori quvvatli PET tog'-kon tomining tomining spetsifikatsiyasi

Eslatma: MD mashina yo‘nalishini, TD esa ko‘ndalang yo‘nalishni bildiradi.

Haqida MTTVS^® zavod

MTTVS^®Geosynthetics kuchli kompaniya. Geosintetikani tadqiq qilish, ishlab chiqish, ishlab chiqarish, ilgari surish va qo'llashga ixtisoslashgan va geosintetika bo'yicha dunyodagi yetakchi yetkazib beruvchi hisoblanadi. 2014 yilda tashkil etilgan va Xitoyning Shandong shahrida joylashgan bo'lib, ISO9001, ISO14001 va ISO45001 xalqaro nufuzli boshqaruv tizimi sertifikatlariga ega. Bizda 10 dan ortiq xalqaro ilg'or uskunalar ishlab chiqarish liniyalari va katta professional muhandislik va texnik jamoa mavjud. Biz mijozlar uchun maksimal qiymat yaratish uchun asosiy bozorni muvaffaqiyatli ishlab chiqdik va birlashtirdik. Biz mijozlarimiz mahsulotlarining ish faoliyatini yaxshilash uchun innovatsion va ishonchli geosintetikani ishlab chiqamiz, ishlab chiqaramiz va taqdim etamiz.

Bizning asosiy biznesimiz geotekstillar, geomembranalar, geogridlar, geoelementlar, uch o'lchovli kompozit drenaj tarmoqlari, ekologik qoplar, drenaj plitalari, 3D geomatlar, plastmassa-bir martalik xizmatlar va mahsulotlarni ishlab chiqarish va eksport qilishdir. xavfsizlik panjarasi, geosintetik gil layneri (Bentonite GCL), ko'r ariq, moslashuvchan o'tkazuvchan shlang, ikki tomonlama yo'naltirilgan plastmassa, kon uchun geosintetika va boshqalar.

Mahsulotlarimiz dunyoning 56 davlatiga eksport qilinmoqda. Bizning asosiy mijozlarimiz AQSh, Germaniya, Pokiston, Hindiston, Keniya, Vetnam, Mirru, Ukraina, Uganda, Boliviya, Ekvador, Avstraliya, Frantsiya, Shvetsiya, Buyuk Britaniya, Gonkong, Vengriya, Yangi Zelandiya, Polsha, Meksika, Braziliya, Bangladesh, Tailand, Malayziya, Indoneziya, Singapur, Filippin, Shri-Lanka, BAA, Saudiya Arabistoni, Qatar, Gana, Efiopiya, Somali, Nigeriya, Janubiy Afrika, Svazilend, Mo'g'uliston va boshqalar.

Bugungi kunda biz nafaqat eng sifatli geosintetika mahsulotlarini ishlab chiqaramiz, balki professional dizayn va o'rnatish xizmatlarini ham taqdim etamiz. OEM, ODM, maxsus ishlab chiqish va ishlab chiqarish ham ta'minlanishi mumkin. MTTVS^®Geosynthetics - ishlab chiqarish, reklama va sotish sohasida kuchli brend ishlab chiqaruvchisi. Dunyo bo'ylab turli ilovalar va bozorlarda ilg'or echimlar va mahsulotlarni taqdim etish orqali MTTVS^® Geosintetik sanoat standartlarini o'rnatishda davom etmoqda va eng muhim etakchiga aylanadi.

Hamkorlikni muhokama qilish uchun global sanoat hamkorlarini xush kelibsiz!

MTTVS^® geosintetika sizga ishonishingiz mumkin.
